Danfoss VLT series Programming Guide

8.3 Object 0x2000: SAB Temperatures
This object shows the temperature measured on the power
card, control card, and SAB card in °C.
Attribute Value
Index 0x2000
Description Temperature
Object code Array
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range 0x03
Default value 0x03
Data type UNSIGNED16
Sub-index 0x01
LCP parameter number 16-34
Description Temperature power card
Access Read only
PDO mapping Yes
Object code Var
Data type SIGNED16
Unit °C
Sub-index 0x02
LCP parameter number 16-39
Description Temperature control card
Access Read only
PDO mapping Yes
Object code Var
Data type SIGNED16
Unit °C
Sub-index 0x03
LCP parameter number 16-31
Description Temperature SAB card
Access Read only
PDO mapping Yes
Object code Var
Data type SIGNED16
Unit °C
Table 8.8 Object 0x2000: SAB Temperatures
8.4
Object 0x2001: DC-link Related Values
This object shows several DC-link voltages and currents.
Attribute Value
Index 0x2001
Description DC-link related values
Object code Record
Attribute Value
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range 0x07
Default value 0x07
Sub-index 0x01
LCP parameter number 51-73
Description DC-link total current
Access Read only
PDO mapping Yes
Object code Var
Data type REAL
Unit Ampere
Sub-index 0x02
LCP parameter number –
Description UDC 1 current
Access Read only
PDO mapping Yes
Object code Var
Data type REAL
Unit Ampere
Sub-index 0x03
LCP parameter number –
Description UDC 2 current
Access Read only
PDO mapping Yes
Object code Var
Data type REAL
Unit Ampere
Sub-index 0x04
LCP parameter number 16-30
Description DC-link voltage
Access Read only
PDO mapping Yes
Object code Var
Data type SIGNED16
Unit Volt
Sub-index 0x05
LCP parameter number 51-74
Description DC leakage current
Access Read only
PDO mapping Yes
Object code Var
Data type REAL
Unit Ampere
Sub-index 0x06
LCP parameter number –
Description DC-link voltage readout
SAB Parameter Description Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 359
8 8
