8.22 Object 0x2071: Guide Value Reference
Speed Limit
This SAB object is identical to the drive object (see
chapter 7.9.6.2 Parameter: Guide Value Reference Speed Limit
(0x2071)).
8.23 Object 0x2072: Guide Value Reference
Target Velocity
This SAB object is identical to the drive object (see
chapter 7.9.6.3 Parameter: Guide Value Reference Target
Velocity (0x2072)).
8.24 Object 0x2073: Guide Value Reference
Acceleration
This SAB object is identical to the drive object (see
chapter 7.9.6.4 Parameter: Guide Value Reference Acceleration
(0x2073)).
8.25 Object 0x2074: Guide Value Reference
Deceleration
This SAB object is identical to the drive object (see
chapter 7.9.6.5 Parameter: Guide Value Reference Deceleration
(0x2074)).
8.26
Object 0x3000: External Encoder
Conguration
This SAB object (and all of its sub-objects) is identical to
the drive object (see chapter 7.21.6.1 Parameters 51-30 and
51-34 to 51-40: External Encoder Conguration (0x3000)).
8.27
Object 0x3001: External Encoder
Enable
This SAB object is identical to the drive object (see
chapter 7.21.6.3 Parameter 51-31: External Encoder Enable
(0x3001)).
8.28
Object 0x4004: Serial String
This SAB object is identical to the drive object (see
chapter 7.22.5 Parameter 15-51: Serial String (0x4004)).
8.29
Object 0x400A: Communication
Settings
This object can be used to control the IP settings.
Usually the PLC/master controls and writes these objects.
Sub-index 0x01:
Not applicable for Ethernet POWERLINK
®
.
0: IP communication (EoE) disabled.
1: IP addresses congured manually.
Sub-index 0x02:
IP address for the device.
For Ethernet POWERLINK
®
: 192.168.100.NODE_ID (where
NODE_ID is the node ID for the Ethernet POWERLINK
®
slave).
Sub-index 0x03:
Not applicable for Ethernet POWERLINK
®
.
IP mask for the device.
Sub-index 0x04:
Not applicable for Ethernet POWERLINK
®
.
IP gateway for the device.
Sub-index 0x08:
MAC address of the device.
Sub-index 0x0D:
Topology conguration of the device.
0: Line topology mode.
1: Ring topology mode (needed for ring redundancy
network congurations).
For details on the wiring, see the VLT
®
Integrated Servo
Drive ISD 510 System Operating Instructions.
Attribute Value
Index 0x400A
Name Communication settings
Object code Record
Data type COMM_SETTINGS
Sub-index 0x00
Access Read only
PDO mapping Yes
Value range 0x00–0xFF
Default value 13
Sub-index 0x01
LCP Parameter number
12-00 EtherCAT
®
only:
0: Disabled
1: Manually congured IP
Name IP conguration
Data type UNSIGNED8
Access Read only
PDO mapping Yes
Value range 0x00–0xFF
Default value 0
Sub-index 0x02
LCP Parameter number 12-01
Additionally for Ethernet POWERLINK
®
12-60 (last number of the IP address)
Name IP address
Data type UNSIGNED32
Access Read only
PDO mapping Yes
Value range – [maximum 200 characters]
Default value 0xC0A864EF
SAB Parameter Description
VLT
®
Integrated Servo Drive ISD
®
510 System
364 Danfoss A/S © 01/2017 All rights reserved. MG36D102
