CAM error bit Command
error
Description
15 14
X
Tried to activate a CAM when there is already a buered CAM (see
chapter 2.4.5.1 Activating a CAM prole).
or
An invalid CAM prole number is selected in the CAM prole selector. This can
either be an out of range number or an invalid prole.
X Guide value reversed while an advanced CAM is active or blending is active.
X X Error during CAM blending: The non-cyclic end of the blending would be after the
end of the new CAM prole or would be outside of the cycle.
Table 7.155 Denition of CAM Error Versus Command Error
Attribute Value
Index 0x3805
LCP parameter number
Name CAM prole status
Object code Var
Data type UNSIGNED16
Sub-index 0x00
Access Read only
PDO mapping Optional
Value range See Table 7.155.
Default value No
Table 7.156 0x3805: CAM Prole Status
7.14.9 Parameter: CAM Slave Oset (0x3807)
This object contains an oset value to the slave position of a CAM. When using the slave position as a relative value, only
changing the value of object CAM slave oset during operation has an eect. At the beginning of a CAM, the oset value is
compensated by the internal oset that is calculated for relative operation.
Objects for Guide value
oset (master) and for slave oset can be used in parallel, meaning it is possible to have a master
and a slave oset at the same time.
CAM slave oset accepts negative values. The values are always added to the current value.
The value of the CAM slave oset is given in revolutions of rotor position. Changing a value has an immediate eect if the
axis is processing a CAM.
Attribute Value
Index 0x3807
LCP parameter number
Name CAM slave oset
Object code Var
Data type FLOAT
Sub-index 0x00
Access Read/write
PDO mapping Optional
Value range FLOAT
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
304 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
