Attribute Value
Index 0x3900
Name Gear ratio
Object code Array
Data type INTEGER32
Sub-index 0x00
Description Number of entries
Access Read only
PDO mapping No
Value range UNSIGNED8
Default value 0x02
Sub-index 0x01
LCP parameter number –
Description Gear ratio numerator
Access Read/write
PDO mapping Optional
Value range INTEGER32
Default value 1
Sub-index 0x02
LCP parameter number –
Description Gear ratio denominator
Access Read/write
PDO mapping Optional
Value range INTEGER32
Default value 1
Table 7.166 0x3900: Gear Ratio
7.15.2 Parameter: Gear Synchronization Option Code (0x3901)
Indicates what action is performed when the Gear In Pos functionality is used but it is not possible to sync to that position.
Attribute Value
Index 0x3901
LCP parameter number –
Name Gear synchronization option code
Object code Var
Data type INTEGER16
Sub-index 0x00
Access Read/write
PDO mapping Optional
Value range 0: Raise a command error
1: Sync to the next guide value cycle
Default value 0
Table 7.167 0x3901: Gear Synchronization Option Code
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
310 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
