7.18.17 Parameter 51-65: Touch Probe 2 Negative Edge Counter (0x60D8)
This object provides a continuous counter that is incremented with each negative edge at touch probe 2. The counter is
only valid if the touch probe input is enabled (bit 8 is set to 1 in object 0x60B8).
For single event measuring, only the value of bit 0 is evaluated. For continuous measuring, the value is an unsigned 16-bit
value with overow.
Attribute Value
Index 0x60D8
LCP parameter number 51-65
Name Touch probe 2 negative edge counter
Object code Var
Data type UNSIGNED16
Sub-index 0x00
Access Read only
PDO mapping Optional
Value range UNSIGNED16
Default value –
Table 7.202 0x60D8: Touch Probe 2 Negative Edge Counter
7.19
Tracing Objects
7.19.1 Parameter: Signal Tracer Control (0x5000)
This object is used to congure and control the tracing of the servo drive internal signals. The object is not visible in the
LCP, so the sub-indexes do not have LCP parameter numbers.
Attribute Value
Index 0x5000
Name Signal tracer control
Object code RECORD
Sub-index 0x00
Description Value of highest sub-index
Access Read only
PDO mapping No
Default value 0x09
Sub-index 0x01
Description Trace control ags
Access Read/write
Data type UNSIGNED16
PDO mapping No
Value range See Table 7.204.
Default value –
Sub-index 0x02
Description Trace control
Access Read/write
Data type UNSIGNED16
PDO mapping No
Value range 0, 1
Default value –
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 327
7 7
