Danfoss VLT series Programming Guide

Variable
name
Data type Default
value
Description
Done BOOL CAM prole has been
written to the le.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Table 6.70 DD_SaveBasicCamToFile_ISD51x
6.5.8 SAB
6.5.8.1 SAB_REF
Represents the state of an ISD 510 Servo Access Box. It
handles the PDO communication and the internal state. To
use the SAB-related function blocks, instantiate 1 function
block for each SAB used. Also, connect the inputs and
outputs to the objects that are mapped in the
development environment for synchronous communication
(see chapter 6.3.1.2 Creating a TwinCAT
®
Project and
chapter 6.4.1.2 Creating an Automation Studio ™ Project).
SAB_REF
ModuleOkBOOL
NodeNumberUSINT
SlotNameSTRING[80]
TPDOUDINT[0..8]
UDINT[0..8]RPDO
130BE953.10
Illustration 6.83 SAB_REF in Automation Studio™
SAB_REF
WcStateBOOL
StateUINT
NodeNumberT_AmsPort
AmsNetldT_AmsNetldArr
TPDOARRAY[0..8] OF-
UDINT
ARRAY[0..8] OF UDINTRPDO
130BE954.10
Illustration 6.84 SAB_REF in TwinCAT
®
6.5.8.2 DD_Power_SAB
Controls the power for the output lines (On or O). The
Enable input enables the DC-link voltage on the output
lines and not the function block itself.
DD_Power_SAB
Sab
EnableBOOL
SAB_REF
BOOLStatus
BOOLValid
BOOL
DD_ERROR_ISD51x
ErrorInfo
Error
TimeLimitTIME
130BE965.10
Illustration 6.85 DD_Power_SAB
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Enable BOOL FALSE If this input is true, DC-link
voltage for the lines is enabled.
TimeLimit TIME t#0ms Timeout after which an error is
signaled if the Status has not
changed to TRUE while Enable
is TRUE. Set the value to 0 to
disable the time limit.
VAR_OUTPUT
Status BOOL Eective state of the DC-link
voltage on the output lines.
Valid BOOL If TRUE, the function block has
a valid set of outputs.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and instance
identier.
See chapter 6.5.2.3 Error
Indication.
Table 6.71 DD_Power_SAB
If the DD_Power_SAB function block is called when Enable
= TRUE while in Standby state, the SAB state changes to
Operation enabled.
The error variable is set to TRUE if the Enable input is TRUE
for the time specied in the input TimeLimit, while the
Status remains FALSE. It indicates a hardware problem with
the power stage. If power fails, also during operation, it
generates a transition to the Fault state.
Only issue 1 function block DD_Power_SAB per SAB.
The Enable input in this function block is not an Enable
input as described in chapter 6.5.2.2 Function Blocks with
Programming Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 221
