Danfoss VLT series Programming Guide

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
reserved ss reserved tor reserved vel reserved pos
MSB LSB
Table 7.210 0x2054: Target Reached Option Code
Legend:
pos = position controlled
vel = velocity controlled
tor = torque controlled
ss = standstill detection
Value Denition for bits 0, 4, and 8 Denition for bit 12
0 Target reached bit is evaluated based on the actual value using
the window parameters.
Standstill bit is evaluated based on the actual value
using the window parameters.
1 Target reached bit is evaluated based on the demand value. Standstill bit is evaluated based on the demanded
value.
Table 7.211 Value Denition for Target Reached Option Code
7.20.3 Parameter 50-43: Following Error Option Code (0x2055)
This object denes the reaction of the servo drive when the lag window is exceeded. This option code is not supported in
csp and csv.
If a following error (lag error) occurs, the used prole velocity may be exceeded. Limit the speed used to try to catch up the
lag error in object 0x6080 (see chapter 7.5.5 Parameter 52-37: Maximum Motor Speed (0x6080)). Dierent reactions to a lag
error can be set, according to the needs of the application.
Attribute Value
Index 0x2054
LCP parameter number 50-43
Name Following error option code
Object code Var
Data type INTEGER16
Sub-index 0x00
Access Read/write
PDO mapping Optional
Value range See Table 7.213.
Default value 0
Table 7.212 0x2055: Following Error Option Code
Value Denition
0 No reaction, warning is raised.
+1 Ramp down with quick stop ramp and remain in state Operation enabled.
+2 Ramp down with quick stop ramp and transition to state Fault.
+3 Ramp down with current limit and remain in state Operation enabled.
+4 Ramp down with current limit and transition to state Fault.
+5 Transition to state Switch on disabled (disable servo drive function; motor is free to rotate).
Table 7.213 Denition of Values for Following Error Option Code
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
332 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
