Danfoss VLT series Programming Guide

Attribute Value
Value range DOMAIN
Default value –
Table 7.207 0x5004: Trace Signal Info
7.20 Option Code Objects
7.20.1 Parameter 50-41: Fault Reaction Option Code (0x605E)
This object indicates what action is performed when a fault is detected in the servo drive. The slow down ramp is the
deceleration value of the used mode of operation.
Attribute Value
Index 0x605E
LCP parameter number 50-41
Name Fault reaction option code
Object code Var
Data type INTEGER16
Sub-index 0x00
Access Read/write
PDO mapping Optional
Value range 0
Default value 0 (Disabled servo drive function, motor is free to rotate.)
Table 7.208 0x605E: Fault Reaction Option Code
7.20.2 Parameter 50-42: Target Reached Option Code (0x2054)
This object indicates how the target reached bit in the Statusword (0x6041) is evaluated. Dierent settings can be used for
the dierent modes of operations: position, velocity, or torque controlled.
Attribute Value
Index 0x2054
LCP parameter number 50-42
Name Target reached option code
Object code Var
Data type INTEGER16
Sub-index 0x00
Access Read/write
PDO mapping Optional
Value range See Table 7.210.
Default value 0
Table 7.209 0x2054: Target Reached Option Code
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 331
7 7
