Danfoss VLT series Programming Guide

DD_ReadParameter_SAB
Sab
EnableBOOL
SAB_REF
BOOLValid
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
DWORD
AbortCode
pBuer
UDINT
BuerSize
UDINT
UDINT
DataLength
Error
IndexUINT
Subindex
USINT
130BE975.10
Illustration 6.95 DD_ReadParameter_SAB
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Enable BOOL FALSE Get the value of the
parameter continuously while
enabled
Index UINT 0 Index of the object to be read.
Subindex USINT 0 Sub-index of the object to be
read.
pBuer UDINT 0 Pointer to a buer where the
read data will be placed (use
ADR() function).
BuerSize UDINT 0 Maximum size of the read
data (size of the provided
buer given in byte; use
SIZEOF() function)
VAR_OUTPUT
Valid BOOL The function block has a valid
output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
AbortCode DWORD SDO abort code if there is an
error. Available in the list of
constants: SdoAbortCodes.
DataLength UDINT Length of the read data [Byte].
Table 6.81 DD_ReadParameter_SAB
6.5.8.13 DD_WriteParameter4_SAB
This function block asynchronously writes general objects
of up to 4 bytes to the object dictionary of the SAB. For
the index and the sub-index of the parameters, see
chapter 8 SAB Parameter Description.
The data needs to be written to the device asynchronously
and is therefore not available in the SAB immediately.
DD_WriteParameter4_SAB
Sab
ExecuteBOOL
SAB_REF
BOOLDone
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
DWORD
AbortCode
Length
USINT
Value
DWORD
Error
IndexUINT
Subindex
USINT
130BE976.10
Illustration 6.96 DD_WriteParameter4_SAB
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Execute BOOL FALSE Write the value of the
parameter at rising edge.
Index UINT 0 Index of the object to be
written.
Subindex USINT 0 Sub-index of the object to be
written.
Length USINT 0 Length of the data to be
written [Byte].
Value DWORD 0 New value of the specied
parameter.
VAR_OUTPUT
Done BOOL The value has been
successfully written to the
device.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
AbortCode DWORD SDO abort code if there is an
error. Available in the list of
constants: SdoAbortCodes.
Table 6.82 DD_WriteParameter4_SAB
Programming Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 227
6
6
