Danfoss VLT series Programming Guide

Attribute Value
PDO mapping No
Default value 0x01
Sub-index 0x01
LCP parameter number 16-66
Description Physical outputs
Access Read/write
Data type UNSIGNED32
PDO mapping Optional
Value range See Table 7.233.
Default value 0
Table 7.232 0x60FE: Digital Outputs
31 1 0
reserved set brake
MSB LSB
Table 7.233 0x60FE: Digital Outputs
Value Denition
0 Switch o (do not set brake).
1 Switch on (set brake).
Table 7.234 Denition of Values for Bit 0
NOTICE
The digital output can be read using object 0x2006 (see chapter 7.22.12 Parameter 50-08: Motion and Input Status
(0x2006)). It can be set in various ways, depending on the conguration of the digital output (see
chapter 7.21.5 Parameter 52-05: Digital Output Conguration (0x2FFF)).
7.21.5 Parameter 52-05: Digital Output Conguration (0x2FFF)
The digital output can be used to power external sensors,
for example an external encoder. It can be switched on or
o as follows:
•
Manually.
•
Automatically by the Digital CAM Switch
functionality.
•
Automatically by the ISD CAM Mode.
This object is used to set the digital output conguration - it species which source should be used for switching the digital
output on or o.
Table 7.236 denes the possible digital output congurations.
Attribute Value
Index 0x2FFF
LCP parameter number 52-05
Name Digital output conguration
Object code Var
Data type UNSIGNED8
Sub-index 0x00
Access Read/write
PDO mapping Yes
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 339
7 7
