Danfoss VLT series Programming Guide

Attribute Value
Default value 0
Table 7.258 0x5020: Control Source
7.22.12 Parameter 50-08: Motion and Input Status (0x2006)
This object contains the motion status (independent on the current mode of operation), and the state of the input switches
(independent of the conguration of the digital inputs).
Attribute Value
Index 0x2006
LCP parameter number 50-08
Name Motion and input status
Object code Var
Data type UNSIGNED16
Sub-index 0x00
Access Read only
PDO mapping Optional
Value range See Table 7.260.
Default value –
Table 7.259 0x2006: Motion and Input Status
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
tp2 tp1 hom rl ll di2 di1 do nLim pLim neg pos st con dec acc
MSB LSB
Table 7.260 0x2006: Motion and Input Status
Digital input:
di1: State of input Digital 1 input.
di2: State of input Digital 2 input.
ll: State of Left Limit input.
rl: State of Right Limit input.
hom: State of Home input.
tp1: State of Touch probe 1 input (object 0x60B9, bit 1 or 2).
tp2: State of Touch probe 2 input (object 0x60B9, bit 9 or 10).
The state is coded as 0 = inactive; 1 = active for all dierent kinds of inputs. If no such input is congured, the value is set
to 0.
Digital output:
do: State of the digital output
The state is coded as 0 = inactive; 1 = active. It is not possible to change the state of the digital output using this object.
Software position limits:
pLim: Positive software limit reached (see chapter 2.3.4.2 Software Position Limit)
nLim: Negative software limit reached (see chapter 2.3.4.2 Software Position Limit)
Motion status:
acc: The servo drive is accelerating (increasing the absolute value of the velocity); Is determined based on the actual value.
dec: The servo drive is decelerating (decreasing the absolute value of the velocity); Is determined based on the actual value.
con: Velocity is constant. The velocity can be 0.
st: Velocity is constant. The velocity is 0.
pos: Positive direction: The position is increasing.
neg: Negative direction: The position is decreasing.
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 353
7 7
