7.22.15 Voltage Objects
7.22.15.1 Parameter 16-30: DC Link Voltage (0x2003)
This value provides the measured DC-link voltage. The value is given in Volt.
Attribute Value
Index 0x2003
LCP parameter number 16-30
Name DC link voltage
Object code Var
Data type INTEGER16
Sub-index 0x00
Access Read only
PDO mapping Optional
Value range –
Default value –
Table 7.264 0x2003: DC Link Voltage
7.22.15.2 Parameter 50-06: Auxiliary Voltage (0x200E)
This object provides the voltage of U
AUX
. The value is given in Volt.
Attribute Value
Index 0x200E
LCP parameter number 50-06
Name Auxiliary voltage
Object code Var
Data type FLOAT
Sub-index 0x00
Access Read only
PDO mapping Optional
Value range –
Default value –
Table 7.265 0x200E: Auxiliary Voltage
7.22.16 Parameter 16-19, 16-31, 16-34, 16-39: Temperature (0x2000)
This object contains several internal temperatures of the device. All the values are given in °C.
Sub-index 1 contains the temperature of the module.
Sub-index 2 contains the temperature from the internal sensor 1.
Sub-index 3 contains the temperature from the internal sensor 2.
Sub-index 4 contains the temperature of the motor winding.
Attribute Value
Index 0x2000
Name Temperature
Object code Array
Sub-index 0x00
Description Value of highest sub-index
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
356 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
