Danfoss VLT series Programming Guide

Attribute Value
Value range FLOAT
Default value –
Sub-index 0x02
LCP Parameter number –
Description Measurement limit current
Access Read only
Data type FLOAT
PDO mapping Optional
Value range FLOAT
Default value –
Sub-index 0x03
LCP Parameter number 50-24
Description Maximum congured speed
Access Read only
Data type FLOAT
PDO mapping Optional
Value range FLOAT
Default value Depends on motor size
Sub-index 0x04
LCP Parameter number 50-26
Description Number of pole pairs
Access Read only
Data type UNSIGNED8
PDO mapping Optional
Value range FLOAT
Default value –
Sub-index 0x05
LCP Parameter number –
Description Measurement limit brake current
Access Read only
Data type FLOAT
PDO mapping Optional
Value range FLOAT
Default value –
Table 7.263 0x5100: Physical Limits
Sub-index 01: Measurement Limit Current
This object contains the maximum measurable current. The value is given in Ampere.
Sub-index 02: Measurement Limit Voltage
This object contains the maximum measurable voltage. The value is given in Volt.
Sub-index 03: Maximum Congured Speed
This object contains the maximum congured speed. The value is given in revolutions per minute.
Sub-index 04: Number of Pole Pairs
This object contains the number of pole pairs.
Sub-index 05: Measurement Limit Brake Current
This object contains the maximum measurable brake current. The value is given in Ampere.
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 355
7 7

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
