Danfoss VLT series Programming Guide

Variable
name
Data type Default
value
Description
VAR_IN_OUT
Slave AXIS_REF_ISD51x Reference to the slave axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
CamTable STRING[80] Reference to CAM
description (le name of
CAM prole on the PLC).
VAR_INPUT
Execute BOOL FALSE Selection at rising edge
CamTableID USINT 0 Identier of CAM table to
be used in the
MC_CamIn_ISD51x function
block. Numbers 1–8 are
available CAM buers.
MasterAb-
solute
BOOL FALSE TRUE = absolute
coordinates.
FALSE = relative
coordinates.
SlaveAbsolute BOOL FALSE TRUE = absolute
coordinates.
FALSE = relative
coordinates.
Cyclic BOOL TRUE TRUE = cyclic.
FALSE = non-cyclic.
pDevice UDINT 0
Automation Studio™ only:
Pointer to the device name
on which the CAM le is
located.
Path E_OpenPat
h
PATH_GE
NERIC
TwinCAT
®
only: The
variable of this type selects
generic or 1 of the
TwinCAT
®
system paths on
the target device.
PatternFile STRING[80] “ Name of the pattern le
on the PLC in case the
CAM prole contains a
pattern alignment.
VAR_OUTPUT
Done BOOL CAM prole and congu-
ration have been
downloaded; Parsing was
successful.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Variable
name
Data type Default
value
Description
ParseError WORD Detailed information on
the type of error if there is
a CAM parsing failure.
ParseE-
rrorDebug
DWORD Depending on the cause
given in the output
ParseError, additional
debug information is given
here. Available in the list
of constants CamParsin-
gErrors.
Table 6.52 MC_CamTableSelect_ISD51x
6.5.6.2 MC_CamIn_ISD51x
This function block engages the CAM. The command is
transferred immediately and, if ChangeImmediate is TRUE, it
is also executed immediately.
MC_CamIn_ISD51x
Master
ExecuteBOOL
MGUIDE_-
VALUE_REF-
_ISD51x
Slave
AXIS_REF-
_ISD51x
BOOLInSync
BOOLBusy
BOOLCommandAborted
BOOL
BOOLError
DD_ERROR_ISD51xErrorInfo
BOOLEndOfProle
Active
MasterOsetDINT
CamTableIDUSINT
ChangeImmediateBOOL
UseBlendingDistanceBOOL
BlendingDistanceUDINT
SwitchControlSetByCamBOOL
StartDelayDD_CAM_-
DELAY_MODE-
_ISD51x
SlaveOsetREAL
130BE956.10
Illustration 6.73 MC_CamIn_ISD51x
Variable
name
Data type Default
value
Description
VAR_IN_OUT
Master GUIDE_VALUE_REF_IS
D51x
Reference to the master
axis.
See Table 6.54.
Slave AXIS_REF_ISD51x Reference to the slave axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Execute BOOL FALSE Start at rising edge.
MasterOset DINT 0 Oset of the master shaft
to CAM [guide value unit].
Programming Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 213
6
6
