Danfoss VLT series Programming Guide

Variable
name
Data
type
Default
value
Description
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Communica-
tionReady
BOOL Network is initialized and
ready for communication.
ReadyFor-
PowerOn
BOOL SAB is ready to enable the
power on the lines (mains
voltage is applied on the
SAB).
PowerOn BOOL TRUE shows that the power is
switched on at the output
lines.
SabWarning BOOL Warning(s) present on the
SAB.
SabError BOOL Error(s) present on the SAB.
Table 6.73 DD_ReadSabInfo_SAB
6.5.8.5 DD_ReadSabError_SAB
This function block presents general SAB errors unrelated
to the function blocks (for example, overtemperature in
the SAB). The output SabErrorID gives the last error that
occurred in the SAB (see chapter 9.3.2 Warnings and
Alarms).
The output data needs to be read from the device and is
therefore not immediately available.
DD_ReadSabError_SAB
Sab
EnableBOOL
SAB_REF
BOOLValid
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
WORD
SabErrorID
Error
130BE968.10
Illustration 6.88 DD_ReadSabError_SAB
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Enable BOOL FALSE Get the SAB information
continuously while enabled.
VAR_OUTPUT
Valid BOOL The function block has a valid
set of outputs.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
SabErrorID WORD The value of the SAB error.
Available in the list of
constants: SabErrorCodes.
Table 6.74 DD_ReadSabError_SAB
6.5.8.6 DD_ReadSabWarning_SAB
This function block presents general SAB warnings
unrelated to the function blocks (for example, high
temperature in the SAB). The output SabWarningID gives
the last warning that occurred in the SAB (see
chapter 9.3.2 Warnings and Alarms).
The output data needs to be read from the device and is
therefore not immediately available.
DD_ReadSabWarning_SAB
Sab
EnableBOOL
SAB_REF
BOOLValid
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
WORD
SabWarningID
Error
130BE969.10
Illustration 6.89 DD_ReadSabWarning_SAB
Programming Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 223
6
6
