Danfoss VLT series Programming Guide

Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Enable BOOL FALSE Get the SAB information contin-
uously while enabled.
VAR_OUTPUT
Valid BOOL The function block has a valid
set of outputs.
Busy BOOL The function block is not
nished and new output values
are to be expected.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and instance
identier.
See chapter 6.5.2.3 Error
Indication.
SabWar-
ningID
WORD The value of the SAB warning.
Available in the list of constants:
SabErrorCodes.
Table 6.75 DD_ReadSabWarning_SAB
6.5.8.7 DD_ReadVersion_SAB
This function block reads the rmware version and the
serial number of the SAB. Done is TRUE when the data-
outputs are valid. The version number consists of a major,
a minor, and beta version number (see chapter 8.29 Object
0x400A: Communication Settings).
The output data needs to be read from the device and is
therefore not immediately available.
DD_ReadVersion_SAB
Sab
ExecuteBOOL
SAB_REF
BOOLDone
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
STRING(18)
SerialNumber
UINT
MajorVersionNo
UINT
MinorVersionNo
UINT
BetaVersionNo
UINT
SoftwareType
Error
130BE970.10
Illustration 6.90 DD_ReadVersion_SAB
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Execute BOOL FALSE Read the information at
rising edge.
VAR_OUTPUT
Done BOOL The values have successfully
been read from the device.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
SerialNumber STRING[18] Serial number of the SAB.
MajorVer-
sionNo
UINT Major rmware version
number.
MinorVer-
sionNo
UINT Minor rmware version
number.
BetaVer-
sionNo
UINT Beta rmware version
number.
SoftwareType UINT Loaded software type.
Table 6.76 DD_ReadVersion_SAB
6.5.8.8 DD_UpdateFirmware_SAB
This function block updates the rmware of the SAB, which
can only be carried out in Standby state. Carry out a power
cycle to use the SAB after updating. For more details on
the rmware update, see chapter 3.8 Firmware Update.
DD_UpdateFirmware_SAB
Sab
ExecuteBOOL
SAB_REF
BOOLDone
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
Error
FileNameSTRING(80)
Path
E_OpenPath
130BE971.10
Illustration 6.91 DD_UpdateFirmware_SAB in TwinCAT
®
Programming
VLT
®
Integrated Servo Drive ISD
®
510 System
224 Danfoss A/S © 01/2017 All rights reserved. MG36D102
