Danfoss VLT series Programming Guide

Attribute Value
Sub-index 0x00
Description Value of highest sub-index
Access Read only
PDO mapping No
Default value 0x08
Sub-index 0x01
Description Trace variable ID 1
Access Read/write
Data type UNSIGNED32
PDO mapping No
Value range See chapter 9.2.3 Trace Signals.
Default value –
Table 7.205 0x5001: Signal Trace Channel IDs
NOTICE
Sub-indexes 02 to 08 are the same as sub-index 1 as shown in Table 7.205. Only the sub-index number increases by 1.
7.19.3 Parameter: Trace Data (0x5002)
This object provides the data after the trace is nished. The samples are 32-bit wide oats in an interleaved way (for
example, if the signals A, B, and C are traced, the data looks like this: A0, B0, C0, A1, B1, and so on).
Attribute Value
Index 0x5002
LCP parameter number –
Name Trace Data
Object code Var
Data type DOMAIN
Sub-index 0x00
Access Read only
PDO mapping No
Value range DOMAIN
Default value –
Table 7.206 0x5002: Trace Data
7.19.4 Parameter: Trace Signal Info (0x5004)
This object contains a list of available trace signals. It can be used to verify whether the trace signal exists in the current
rmware version of the device.
Attribute Value
Index 0x5004
LCP parameter number –
Name Trace signal info
Object code Var
Data type DOMAIN
Sub-index 0x00
Access Read only
PDO mapping No
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
330 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
