DD_ReadDcLinkVoltage_SAB
Sab
EnableBOOL
SAB_REF
BOOLValid
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
INT
Voltage
Error
130BE973.10
Illustration 6.93 DD_ReadDcLinkVoltage_SAB
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Enable BOOL FALSE Get the value of the parameter
continuously while enabled.
VAR_OUTPUT
Valid BOOL The function block has a valid
output.
Busy BOOL The function block is not
nished and new output values
are to be expected.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and instance
identier.
See chapter 6.5.2.3 Error
Indication.
Voltage INT Value of the actual DC-link
voltage [V].
Table 6.79 DD_ReadDcLinkVoltage_SAB
6.5.8.11 DD_ReadParameter4_SAB
This function block asynchronously reads general objects
of up to 4 bytes from the object dictionary of the SAB if
the Enable input is set. For the index and the sub-index of
the parameters, see chapter 8 SAB Parameter Description.
The output data needs to be read from the device and is
therefore not immediately available.
DD_ReadParameter4_SAB
Sab
EnableBOOL
SAB_REF
BOOLValid
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
DWORD
AbortCode
DWORD
Value
Error
IndexUINT
Subindex
USINT
130BE974.10
Illustration 6.94 DD_ReadParameter4_SAB
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Sab SAB_REF Reference to the SAB.
See chapter 6.5.8.1 SAB_REF.
VAR_INPUT
Enable BOOL FALSE Get the value of the parameter
continuously while enabled.
Index UINT 0 Index of the object to be read.
Subindex USINT 0 Sub-index of the object to be
read.
VAR_OUTPUT
Valid BOOL The function block has a valid
output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred within
the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
AbortCode DWORD SDO abort code if there is an
error. Available in the list of
constants: SdoAbortCodes.
Value DWORD Value of the specied
parameter.
Table 6.80 DD_ReadParameter4_SAB
6.5.8.12 DD_ReadParameter_SAB
This function block asynchronously reads general objects
from the object dictionary of the SAB if the Enable input is
set. For the index and the sub-index of the parameters, see
chapter 8 SAB Parameter Description. The output data needs
to be read from the device and is therefore not available
immediately.
Programming
VLT
®
Integrated Servo Drive ISD
®
510 System
226 Danfoss A/S © 01/2017 All rights reserved. MG36D102
