Danfoss VLT series Programming Guide

Code Name Severity
(Warning/
Error/Trip
lock)
Description LCP name
0x4290 Overtem-
perature:
Power
module
Error Overtem-
perature on
power
module.
overtemp
PM
0x4291 Overtem-
perature:
Control card
Error Overtem-
perature on
control PCB.
overtemp CC
0x4295 Overtem-
perature:
Power card
Error Overtem-
perature on
power PCB.
overtemp PC
0x4310 Overtem-
perature:
Motor
Error Overtem-
perature on
motor.
overtemp
motor
0x5112 UAUX
undervoltag
e
Error, trip
lock
Undervoltag
e on
auxiliary
voltage.
undervolt
UAUX
0x5530 EE
Checksum
Error
(parameter
missing)
Trip lock Missing
parameter in
internal
drive cong-
uration.
cong err
0x6320 Parameter
error
Trip lock An internal
parameter
has an
invalid value.
param err
0x7320 Internal
position
sensor error
Trip lock Absolute
position
sensor error.
int sensor
err
0x7380 External
position
sensor error
Error External
encoder
data could
not be read.
ext sensor
err
0x8611 Following
error
Warning,
error
A following
error has
occurred.
following err
0x8693 Homing
error on
entering
homing
mode
Warning Could not
enter
homing
mode (for
example
velocity not
0).
Homing
mode fail
0x8694 Homing
error on
start homing
method
Warning Could not
start homing
method (for
example
drive not in
standstill).
Homing
method fail
0x8695 Homing
error
distance
Warning Homing
distance
reached.
Homing
distance
Code Name Severity
(Warning/
Error/Trip
lock)
Description LCP name
0xFF01 Mechanical
brake failure
Trip lock No brake or
wire failure.
brake mech
fail
0xFF02 Short circuit
in
mechanical
brake
control
Trip lock Short circuit
in brake
control.
brake mech
short
0xFF0A External
interface
power
failure
Error External
interface
power
supply
failure.
ext IF pwr
fail
0xFF60 Timing
violation 1
Trip lock Contact
Danfoss.
timing err 1
0xFF61 Timing
violation 2
Trip lock Contact
Danfoss.
timing err 2
0xFF62 Timing
violation 3
Trip lock Contact
Danfoss.
timing err 3
0xFF63 Timing
violation 4
Trip lock Contact
Danfoss.
timing err 4
0xFF64 Timing
violation 5
Trip lock Contact
Danfoss.
timing err 5
0xFF65 Timing
violation 6
Trip lock Contact
Danfoss.
timing err 6
0xFF70 Firmware:
Package
description
mismatch
Trip lock Firmware
found does
not match
the package
description.
FW pack err
0xFF71 Firmware:
Power cycle
needed
Warning,
error
Firmware
update
transfer is
completed
but a power
cycle is
required
before the
new
rmware is
active.
need
powercycle
0xFF72 Firmware:
Update
started
Warning,
error
Firmware
update in
progress.
The warning
becomes an
error when
an attempt
is made to
enable the
drive in this
state.
FW update
Diagnostics Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 369
9 9

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
