| Using the Web Interface
Navigating the Web Browser Interface
– 85 –
Statistics Shows Interface, Etherlike, and RMON port statistics 138
Chart Shows Interface, Etherlike, and RMON port statistics 138
Cable Test Performs cable diagnostics for selected port to diagnose any cable
faults (short, open etc.) and report the cable length
142
Tru n k
Static 145
Configure Trunk Creates a trunk, specifying port members 145
Configure General 145
Configure Configures trunk connection settings 145
Show Information Displays trunk connection settings 145
Dynamic 147
Configure Aggregator Configures administration key for specific LACP groups 147
Configure Aggregation Port 147
Configure 147
General Allows ports to dynamically join trunks 147
Actor Configures parameters for link aggregation group members on the
local side
147
Partner Configures parameters for link aggregation group members on the
remote side
147
Show Information 153
Counters Displays statistics for LACP protocol messages 153
Internal Displays configuration settings and operational state for the local
side of a link aggregation
154
Neighbors Displays configuration settings and operational state for the
remote side of a link aggregation
156
Configure Trunk 147
Show Displays trunk connection settings 147
Configure Configures trunk connection settings 147
Show Member Show port members of dynamic trunks 147
Mirror 158
Add Sets the source trunks and target port for mirroring 158
Show Shows the configured mirror sessions 158
Statistics Shows Interface, Etherlike, and RMON port statistics 138
Chart Shows Interface, Etherlike, and RMON port statistics 138
Green Ethernet Adjusts the power provided to ports based on the length
of the cable used to connect to other devices
159
RSPAN Mirrors traffic from remote switches for analysis at a destination
port on the local switch
134
Traffic Segmentation 161
Configure Global Enables traffic segmentation globally 161
