| Using the Web Interface
Navigating the Web Browser Interface
– 86 –
Configure Session Configures the uplink and down-link ports for a segmented group
of ports
162
VLAN Trunking Allows unknown VLAN groups to pass through the specified
interface
163
VLAN Virtual LAN 167
Static
Configure VLAN Configures VLAN groups, administrative status, and remote type 170
Modify VLAN and Member Ports Configures group name, status, and member attributes 171
Edit Member by Interface Specifies VLAN attributes per interface 171
Edit Member by Interface Range Specifies VLAN attributes per interface range 171
Dynamic
Configure General Enables GVRP VLAN registration protocol globally 176
Configure Interface Configures GVRP status and timers per interface 176
Show Dynamic VLAN 176
Show VLAN Shows the VLANs this switch has joined through GVRP 176
Show VLAN Member Shows the interfaces assigned to a VLAN through GVRP 176
Tunnel IEEE 802.1Q (QinQ) Tunneling 179
Configure Global Sets tunnel mode for the switch 183
Configure Interface Sets the tunnel mode for any participating interface 184
Protocol 185
Configure Protocol 186
Add Creates a protocol group, specifying supported protocols 186
Show Shows configured protocol groups 186
Configure Interface 187
Add Maps a protocol group to a VLAN 187
Show Shows the protocol groups mapped to each VLAN 187
IP Subnet 189
Add Maps IP subnet traffic to a VLAN 189
Show Shows IP subnet to VLAN mapping 189
MAC-Based 191
Add Maps traffic with specified source MAC address to a VLAN 191
Show Shows source MAC address to VLAN mapping 191
Mirror 193
Add Mirrors traffic from one or more source VLANs to a target port 193
Show Shows mirror list 193
Table 6: Switch Main Menu (Continued)
