TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 201
Hard disk drives / solid state drives
SAS cabling with SAS expander board, one SAS 3.0 controller and one
SAS 2.0 controller
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS 3.0 cable
Y4040-V8
27
Connector MLC 1 on
SAS 3.0 controller 1
in PCI slot 10
SAS 3.0 backplane 1
connector X5
16.2.19
SAS 3.0 cable
Y4040-V8
27
Connector MLC 2 on
SAS 3.0 controller 1
in PCI slot 10
SAS 3.0 backplane 2
connector X5
SAS 2.0 cable
Y3963-V112
15
Connector X3 on
SAS expander board
SAS 2.0 backplane 3
connector X1
16.2.18
SAS 2.0 cable
Y3963-V112
15
Connector X4 on
SAS expander board
SAS 2.0 backplane 4
connector X1
SAS 2.0 cable
Y3963-V151/V101
16
Connector X5 on
SAS expander board
SAS 2.0 backplane 5
connector X1
16.2.18
SAS 2.0 cable
Y3963-V151/V101
16
Connector X6 on
SAS expander board
SAS 2.0 backplane 6
connector X1
SAS 2.0 cable
Y3963-V107
18
Connector MLC 1 on
SAS 2.0 controller 2
in PCI slot 3
Connector MLC 1 on
SAS expander board
16.2.18
SAS 2.0 cable
Y3963-V107
18
Connector MLC 2 on
SAS 2.0 controller 2
in PCI slot 3
Connector MLC 2 on
SAS expander board
