202 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Hard disk drives / solid state drives
SAS cabling with SAS expander board and one SAS 2.0 controller
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS 2.0 cable
Y3963-V112
15
Connector X1 on
SAS expander board
SAS 2.0 backplane 1
connector X1
16.2.20
SAS 2.0 cable
Y3963-V112
15
Connector X2 on
SAS expander board
SAS 2.0 backplane 2
connector X1
SAS 2.0 cable
Y3963-V112
15
Connector X3 on
SAS expander board
SAS 2.0 backplane 3
connector X1
SAS 2.0 cable
Y3963-V112
15
Connector X4 on
SAS expander board
SAS 2.0 backplane 4
connector X1
SAS 2.0 cable
Y3963-V151/V101
16
Connector X5 on
SAS expander board
SAS 2.0 backplane 5
connector X1
16.2.20
SAS 2.0 cable
Y3963-V151/V101
16
Connector X6 on
SAS expander board
SAS 2.0 backplane 6
connector X1
SAS 2.0 cable
Y3963-V151/V101
16
Connector MLC 1 on
SAS 2.0 controller 1
in PCI slot 10
Connector MLC 1 on
SAS expander board
16.2.20
SAS 2.0 cable
Y3963-V151/V101
16
Connector MLC 2 on
SAS 2.0 controller 1
in PCI slot 10
Connector MLC 2 on
SAS expander board
