Gemalto Cinterion EHS6 User Manual

Cinterion
®
EHS6 AT Command Set 
2.12 AT^SCFG
 EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 56 of 513
Write Command
Query/Configure 2G Speech Codec for voice calls
AT^SCFG="Call/Speech/Codec"[, <scc>]
Response(s)
^SCFG: "Call/Speech/Codec", <scc>
OK
ERROR
+CME ERROR: <err>
Write Command
Configure ASC1 interface lines RXD1, TXD1, RTS1, CTS1 shared with GPIO16 - GPIO19 lines and SPI lines
MOSI, MISO, SPI_CS
AT^SCFG="GPIO/mode/ASC1"[, <g_mode>]
Response(s)
^SCFG: "GPIO/mode/ASC1", <g_mode>
OK
ERROR
+CME ERROR: <err>
Write Command
Configure Digital Audio Interface lines TXDDAI, RXDDAI, TFSDAI, SCLK shared with GPIO20 - GPIO23 lines
AT^SCFG="GPIO/mode/DAI"[, <g_mode>]
Response(s)
^SCFG: "GPIO/mode/DAI", <g_mode>
OK
ERROR
+CME ERROR: <err>
Write Command
Configure DCD0 line of ASC0 interface shared with GPIO2
AT^SCFG="GPIO/mode/DCD0"[, <g_mode>]
Response(s)
^SCFG: "GPIO/mode/DCD0", <g_mode>
OK
ERROR
+CME ERROR: <err>
Write Command
Configure DSR0 line of ASC0 interface shared with GPIO3 line and SPI_CLK line of SPI
AT^SCFG="GPIO/mode/DSR0"[, <g_mode>]
Response(s)
^SCFG: "GPIO/mode/DSR0", <g_mode>
OK
ERROR
+CME ERROR: <err>
Write Command
Configure DTR0 line of ASC0 interface shared with GPIO1 line
AT^SCFG="GPIO/mode/DTR0"[, <g_mode>]
Response(s)
^SCFG: "GPIO/mode/DTR0", <g_mode>
OK
ERROR
+CME ERROR: <err>
