JUNOS Internet Software Network Operations Guide: Hardware
342 ! Understanding the Host Module
Figure 140 shows the Routing Engine component of the host module.
Figure 140: Routing Engine Component
Figure 141 shows the MCS component of the host module.
Figure 141: MCS Component
1154
Extractor clip
Extractor clip
PC card slot
Reset button
1178
Extractor clip
Extractor clip
Offline button
LEDs
