MBRAUN LABmaster pro sp - Box Purge Function (Optional); ECO Mode

13 Spare parts
Gas purifier
Page
13 - 4
MB-20-G/MB-200G-W_MB-LABmaster_MB-200 MOD_TP700
Operating Manual - V5.0 - 04/2018 - STD
13.2.3 Box purge function (optional)
No. Name Description Item no.
1 Magnetic valve set VSE, DN4 4600977
2 PVC hose (purging out-
let)
800 mm 2602195
2a Hose clamp 32 … 50 mm 2501116
2b Aluminum tube 42x1, L = 100 mm 2300221
2 Hose + clamp + tube Complete 6000565
3 Non-return valve (pur-
ging outlet)
DN40 7024588
4 HV angle valve MB-EPV-40 (aluminum) 9002531-K
Nickel plated 9002533-K
5 2-way ball valve 3/8” V2A 3240521
13.2.4 ECO Mode
Name Description Item no.
ECO Mode complete Function extension with
ECO Mode
1502000
HV angle valve DN40, ISO-KF 9002531-K
Non-return valve BS DN40 9004611
Flange exhaust DN40 KF 7122812
