4 Transport, installation and commissioning
Installation
MB-20-G/MB-200G-W_MB-LABmaster_MB-200 MOD_TP700
Operating Manual - V5.0 - 04/2018 - STD
Page
4 - 21
Data pH 7 … 8
Particle contamination Filtered to a particle size (diameter) of ≤ 30
μm
Microbiological contamina-
tion (algae, bacteria, fungi)
< 100 cfu/ml
Total dissolved solids ≤ 150 mg / l
4.2.5 Installation vacuum pump
Vacuum pump for gas purification (VG01)
Use ¡ Box pressure regulation
¡ Antechamber cycles
¡ Regeneration cycles
Vacuum pump (VP01) , dedicated to antechamber cycles (optional)
Use For high-quality requirements of box and/or antechamber atmosphere
Equipment for connecting vacuum pumps
Use Connection of the vacuum pumps exhaust (oil mist and exhaust) to op-
erating company’s on-site exhaust line (depressurised)
Material Length as required
KF 25 hose connector
Optional purge kit for vacuum pump
Use Purging of the vacuum pump if contaminated / aggressive gases es-
cape from the antechamber into the vacuum pump
High values of water from the regeneration process of the reactors
Material Purge kit with air filter for scroll pumps
4.2.6 Connecting the system
Prerequisites
¡ The necessary media and corresponding connection equipment are available.
¡ All pressure reducing valves (not included in the scope of delivery for standard sys-
tems) are available. Pressure reducing valves are the responsibility of the operating
company.
¡ Pay special attention to the hazards accompanying the disposal of gases.
