MBRAUN LABmaster pro sp - Specifications; Operation

8B Freezer
Specifications
Page
8B - 2
MB-20-G/MB-200G-W_MB-LABmaster_MB-200 MOD_TP700
Operating Manual - V5.0 - 04/2018 - STD
The freezer / refrigerator temperature is displayed in the Start screen of the touch panel
8B.2 Specifications
Inner dimensions
Height Width Depth
423.0 266.0 162.5 mm
Inner volume: ±18.3 Litre
Cooling Range: +10 °C to … 35 °C (if ambient temp. < 30 °C)
The temperature is controlled by the PLC.
The door of the freezer can be opened and closed with a handle. Additionally the door
can be locked using a key.
8B.3 Operation
Adjusting the freezer parameters
Start Screen ⇨ Menu ⇨ Freezer Box Cooling
Illustration1: parameter
To change the set point:
► Touch the "Setpoint
temperature freezer"
input field.
ð The alphanumeric in-
put screen opens
(refer to the main doc-
umentation for further
information).
► Confirm the entries
by touching the
Enter button.
ð In the "Actual value
freezer" output field,
the current temperat-
ure is shown.
