4 Transport, installation and commissioning
Transport
MB-20-G/MB-200G-W_MB-LABmaster_MB-200 MOD_TP700
Operating Manual - V5.0 - 04/2018 - STD
Page
4 - 7
► If available, use a crane(2c) to lift the gas purifier.
Dimensions and weight
The values are average values of standard systems. For the exact weight and dimen-
sions of your system, refer to delivery papers.
Parameter Value
Height A 850 mm
Width B 600 mm
Depth C 820 mm
Weight 170 kg
