Fig. 7.39: Test signal generator for square signal
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
150
7 Control
ID
Parameter /
Setting
Function Info
1500
SCD_TSIG_
Con
Testsignalgenerator
controlword
Theparameterisresettothe
value0oncompletionofthe
stopprocedure.
OFF(0)
Testsignalgenerator
deactivated
Stop(1) Stoptestsignal
Start(2) Starttestsignal
STOP-Cycle
(3)
TGstopsatendofcurrent
squarecycle
Stop-Zero
(4)
TGstopsnexttime
referencevaluepasses
throughzero
1501
SCD_TSIG_
OutSel
Testsignalgenerator
outputselector
OFF(0) Notused
isdref(1) Flux-formingcurrent
mref(2) Torque
sref(3) Speed
epsref(4) Position
sramp(5) Speed(ramp)
ISQREF(6) q-currentreference
ISDQREF
(7)
d-currentq-current
reference
Table 7.29: Parameters of test signal generator for square and sine signal
