Parameter /
Setting
Function Info
USDQREF
(8)
Setpointvoltagefeed-
forwardcontrol
PRCREF(9) Processcontroller
1502
SCD_TSIG_
Cycles
Numberofrepeatcycles
1503
SCD_TSIG_
Offset
Offsetofsquaresignal
0
Offsetofsquaresignal
(Stage1)
1
Offsetofsquaresignal
(Stage2)
2
3
1504
SCD_TSIG_
Time
Periodofsquaresignal
0 Time(t1)
1 Time(t2)
Table 7.29: Parameters of test signal generator for square and sine signal (continue)
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
151
7 Control
ID
Parameter /
Setting
Function Info
1505
SCD_TSIG_
Amp
Amplitudeofsinesignal
(a)
1506
SCD_TSIG_
Freq
Frequencyofsinesignal
(f)
1507
SCD_TSIG_
SetPhase
Phaseangleofsignal:
Startphaseofcurrent
spacevector
inVFCONandICON
mode
1508
SCD_TSIG_
PRBSTime
PRBSsignalgenerator,
samplingtime
1509
SCD_TSIG_
PRBSAmp
PRBSsignalgenerator,
amplitude
