1510
SCD_TSIG_
SignalType
Signalshape:Sine/delta
SINUS(0) Sinewavegenerator
TRIANGLE
(1)
Trianglewavegenerator
1511
SCD_TSIG_
BreakTime
Breaktime
0
Break(ms)beforesignal
cycle
1
Break(ms)between
positiveandnegative
signalcyclesegment
1512
SCD_TSIG_
SymVal
Symmetryvaluefordelta
signal
Table 7.29: Parameters of test signal generator for square and sine signal (continue)
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
152
7 Control
Fig. 7.40: Example of a PRBS signal
