P203 - MPRO_TAB_PMode is used to define the type of positioning used:
 ABS(0)=Absolute
Absolutepositioning

REL(1)=Relative(aftertargetreached)
Relative positioning after target position reached.

RELatonce(2)=Relative(atonce)
Aborts a current position motion task and moves to the new reference value
starting from the current position.

SPEED(3)=Endless(speedcontrolled)
IfatablevalueissettoSPEED,aninfinitedrivingjobistransmitted.Ifa table
valuewiththesettingABSorRELisadditionallyselected,theinfinite jobisquit
andthenewlyselectedtablevalueisapproachedfromthecurrent position.
Speed
If the servo drive is run with motor control mode "PCON(3) = Position control
mode" (for information on the setting, see Section "Basic settings" on page 107), the
“Mode” and “Speed” lines will be added to the “Setpoint table” screen.
P201 - MPRO_TAB_PSpd is used to define the speed for a driving job.
Acceleration
With ...
 P 193 - MPRO_TAB_TAcc(fortorquecontrol)or
 P 196 - MPRO_TAB_SAcc(forspeedcontrol)or
 P 199 - MPRO_TAB_PAcc(forpositioncontrol)
and indexes 0–15, the accelerations for moving to the setpoint for each individual
driving job can be defined. The input must not be zero.
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
207
8 Motion profile
Deceleration
With ...
 P 194 - MPRO_TAB_TDec(fortorquecontrol)or
 P 197 - MPRO_TAB_SDec(forspeedcontrol)or
 P 200 - MPRO_TAB_PDec(forpositioncontrol)
and indexes 0–15, the deceleration for each individual driving job can be defined.
The input must not be zero.
Wait time in Auto mode
P204 - MPRO_TAB_WaitTime is used to define the wait time before the next
driving job is carried out.
Maximum table index in Auto mode
P206[0] - MPRO_Tab_MaxIdx is used to define the table index up to which driving
jobs will be carried out in one of the auto modes.
Current table index
P207[0] - MPRO_Tab_ActIdx will show the index for the driving job that is currently
active. If parameter P 205 MPRO_TAB_Mode is set to “Para(0)”, a driving set can be
entered and approached directly.
Activation of reference table
The following procedures can be used in order to activate the setpoint table for
operation.
