Position control
The direction of movement is produced when the time-related change in position
reference (speed pre-control value) has exceeded the amount of the standstill
window in the positive or negative direction.
Speed control
The direction of movement is produced when the speed reference has exceeded the
amount of the standstill window in the positive or negative direction.
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
99
6 Encoder
Correction factor
1 2 3 4 5
6 7....
Interpolation
point distance
P 0593
maximum 250
Startposition
P 0591
Correction
interpolation
points
Interpolation point
conter clockwise correction
Interpolation point
clockwise correction
Incorrected Positionvalue (conter-clockwise rotation)
Incorrected Positionvalue (clockwise rotation)
Endposition
P 0592
Legend:
Fig. 6.12: Corrected position value
