Chapter 10: LPC11U3x/2x/1x USB on-chip drivers
10.5.7 _CDC_UNION_1SLAVE_DESCRIPTOR
10.5.8 _CDC_UNION_DESCRIPTOR
10.5.9 _DFU_STATUS
10.5.10 _HID_DESCRIPTOR
HID class-specific HID Descriptor.
Table 180. _CDC_LINE_CODING class structure
Member Description
dwDTERate
uint32_t _CDC_LINE_CODING::dwDTERate
bCharFormat
uint8_t _CDC_LINE_CODING::bCharFormat
bParityType
uint8_t _CDC_LINE_CODING::bParityType
bDataBits
uint8_t _CDC_LINE_CODING::bDataBits
Table 181. _CDC_UNION_1SLAVE_DESCRIPTOR class structure
Member Description
sUnion
CDC_UNION_DESCRIPTORCDC_UNION_DESCRIPTOR _CDC_UNION_1SLAVE_DESCRIPTOR::sUnion
bSlaveInterfaces
uint8_t _CDC_UNION_1SLAVE_DESCRIPTOR::bSlaveInterfaces[1][1]
Table 182. _CDC_UNION_DESCRIPTOR class structure
Member Description
bFunctionLength
uint8_t _CDC_UNION_DESCRIPTOR::bFunctionLength
bDescriptorType
uint8_t _CDC_UNION_DESCRIPTOR::bDescriptorType
bDescriptorSubtype
uint8_t _CDC_UNION_DESCRIPTOR::bDescriptorSubtype
bMasterInterface
uint8_t _CDC_UNION_DESCRIPTOR::bMasterInterface
Table 183. _DFU_STATUS class structure
Member Description
bStatus
uint8_t _DFU_STATUS::bStatus
bwPollTimeout
uint8_t _DFU_STATUS::bwPollTimeout[3][3]
bState
uint8_t _DFU_STATUS::bState
iString
uint8_t _DFU_STATUS::iString
