8.1 How to read this chapter
Table 131 shows the possible pin configuration for the LPC11U3x/2x/1x parts.
UM10462
Chapter 8: LPC11U3x/2x/1x Pin configuration
Rev. 5.5 — 21 December 2016 User manual
Table 131. LPC11U3x/2x/1x pin configurations
Part Package Pin configuration Pin description
LPC11U1x HVQFN33 Figure 15
Table 132
LQFP48 Figure 16 Table 132
TFBGA48 Figure 17 Table 132
LPC11U2x HVQFN33 Figure 15 Table 134
LQFP48 Figure 16 Table 134
LQFP64 Figure 18 Table 134
LPC11U3x HVQFN33 Figure 15 Table 135
LQFP48 Figure 16 Table 135
TFBGA48 Figure 17 Table 135
LQFP64 Figure 18 Table 135
