Chapter 14: LPC11U3x/2x/1x I2C-bus controller
14.10.2 Master Receiver mode
In the master receiver mode, a number of data bytes are received from a slave transmitter
(see Figure 50
). The transfer is initialized as in the master transmitter mode. When the
START condition has been transmitted, the interrupt service routine must load DAT with
the 7-bit slave address and the data direction bit (SLA+R). The SI bit in CON must then be
cleared before the serial transfer can continue.
When the slave address and the data direction bit have been transmitted and an
acknowledgment bit has been received, the serial interrupt flag (SI) is set again, and a
number of status codes in STAT are possible. These are 0x40, 0x48, or 0x38 for the
master mode and also 0x68, 0x78, or 0xB0 if the slave mode was enabled (AA = 1). The
appropriate action to be taken for each of these status codes is detailed in Table 288
. After
a Repeated START condition (state 0x10), the I
2
C block may switch to the master
transmitter mode by loading DAT with SLA+W.
