Chapter 3: LPC11U3x/2x/1x System control block
– Reset from the BOD circuit. In this case, the BOD reset must be enabled in the
BODCTRL register (Table 36
).
• WWDT signal, if the watchdog oscillator is enabled in the PDSLEEPCFG register:
– WWDT interrupt using the interrupt wake-up register 1 (Table 44
). The WWDT
interrupt must be enabled in the NVIC. The WWDT interrupt must be set in the
WWDT MOD register.
– Reset from the watchdog timer.The WWDT reset must be set in the WWDT MOD
register.
• USB wake-up signal interrupt wake-up register 1 (Table 44). For details, see
Section 11.7.6
.
• GPIO group interrupt signal (see Table 44).
Remark: If the watchdog oscillator is running in Power-down mode, its frequency
determines the wake-up time.
Remark: If the application in active mode uses a main clock different from the IRC,
reprogram the clock source for the main clock in the MAINCLKSEL register after waking
up.
3.9.6 Deep power-down mode
In Deep power-down mode, power and clocks are shut off to the entire chip with the
exception of the WAKEUP pin. The Deep power-down mode is controlled by the PMU
(see Chapter 4
).
During Deep power-down mode, the contents of the SRAM and registers are not retained
except for a small amount of data which can be stored in the general purpose registers of
the PMU block.
All functional pins are tri-stated in Deep power-down mode except for the WAKEUP pin.
Remark: Setting bit 3 in the PCON register (Section 4.3.1
) prevents the part from entering
Deep-power down mode.
3.9.6.1 Power configuration in Deep power-down mode
Deep power-down mode has no configuration options. All clocks, the core, and all
peripherals are powered down. Only the WAKEUP pin is powered.
3.9.6.2 Programming Deep power-down mode
The following steps must be performed to enter Deep power-down mode:
1. Pull the WAKEUP pin externally HIGH.
2. Ensure that bit 3 in the PCON register (Table 54
) is cleared.
3. Write 0x3 to the PD bits in the PCON register (see Table 54
).
4. Store data to be retained in the general purpose registers (Section 4.3.2
).
5. Write one to the SLEEPDEEP bit in the ARM Cortex-M0 SCR register.
6. Use the ARM WFI instruction.
