20.1 How to read this chapter
See Table 357 for different flash configurations and functionality.
Remark: In addition to the ISP and IAP commands, a register can be accessed in the
flash controller block to configure flash memory access times, see Section 20.16.4.1
.
UM10462
Chapter 20: LPC11U3x/2x/1x Flash programming firmware
Rev. 5.5 — 21 December 2016 User manual
Table 357. LPC11U3x/2x/1x flash configurations
Type number Flash in kB Configuration Page erase IAP
command
supported
EEPROM
in kB
ISP via UART ISP via USB
MSC
LPC11U12FBD48/201 16 Table 360
no no yes no
LPC11U12FHN33/201 16 Table 360
no no yes no
LPC11U13FBD48/201 24 Table 360
no no yes no
LPC11U14FBD48/201 32 Table 360
no no yes no
LPC11U14FHN33/201 32 Table 360
no no yes no
LPC11U14FHI33/201 32 Table 360
no no yes no
LPC11U14FET48/201 32 Table 360
no no yes no
LPC11U22FBD48/301 16 Table 360
no 1 yes yes
LPC11U23FBD48/301 24 Table 360
no 1 yes yes
LPC11U24FHI33/301 32 Table 360
no 2 yes yes
LPC11U24FBD48/301 32 Table 360
no 2 yes yes
LPC11U24FET48/301 32 Table 360
no 2 yes yes
LPC11U24FHN33/401 32 Table 360
no 4 yes yes
LPC11U24FBD48/401 32 Table 360
no 4 yes yes
LPC11U24FBD64/401 32 Table 360
no 4 yes yes
LPC11U34FHN33/311 40 Table 361
yes 4 yes yes
LPC11U34FBD48/311 40 Table 361
yes 4 yes yes
LPC11U34FHN33/421 48 Table 361
yes 4 yes yes
LPC11U34FBD48/421 48 Table 361
yes 4 yes yes
LPC11U35FHN33/401 64 Table 361
yes 4 yes yes
LPC11U35FBD48/401 64 Table 361
yes 4 yes yes
LPC11U35FBD64/401 64 Table 361
yes 4 yes yes
LPC11U35FHI33/501 64 Table 361
yes 4 yes yes
LPC11U35FET48/501 64 Table 361
yes 4 yes yes
LPC11U36FBD48/401 96 Table 361
yes 4 yes yes
LPC11U36FBD64/401 96 Table 361
yes 4 yes yes
LPC11U37FBD48/401 128 Table 361
yes 4 yes yes
LPC11U37HFBD64/401 128 Table 361
yes 4 yes yes
LPC11U37FBD64/501 128 Table 361
yes 4 yes yes
