NXP Semiconductors LPC11U3x User Manual

UM10462 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2016. All rights reserved.
User manual Rev. 5.5 — 21 December 2016 176 of 523
NXP Semiconductors
UM10462
Chapter 10: LPC11U3x/2x/1x USB on-chip drivers
10.5.13 _MSC_CBW
10.5.14 _MSC_CSW
10.5.15 _REQUEST_TYPE
10.5.16 _USB_COMMON_DESCRIPTOR
Table 187. _MSC_CBW class structure
Member Description
dSignature
uint32_t _MSC_CBW::dSignature
dTag
uint32_t _MSC_CBW::dTag
dDataLength
uint32_t _MSC_CBW::dDataLength
bmFlags
uint8_t _MSC_CBW::bmFlags
bLUN
uint8_t _MSC_CBW::bLUN
bCBLength
uint8_t _MSC_CBW::bCBLength
CB
uint8_t _MSC_CBW::CB[16][16]
Table 188. _MSC_CSW class structure
Member Description
dSignature
uint32_t _MSC_CSW::dSignature
dTag
uint32_t _MSC_CSW::dTag
dDataResidue
uint32_t _MSC_CSW::dDataResidue
bStatus
uint8_t _MSC_CSW::bStatus
Table 189. _REQUEST_TYPE class structure
Member Description
B
uint8_t _REQUEST_TYPE::B
byte wide access member
BM
BM_TBM_T _REQUEST_TYPE::BM
bitfield structure access member
Table 190. _USB_COMMON_DESCRIPTOR class structure
Member Description
bLength
uint8_t _USB_COMMON_DESCRIPTOR::bLength
Size of this descriptor in bytes
bDescriptorType
uint8_t _USB_COMMON_DESCRIPTOR::bDescriptorType
Descriptor Type
