Chapter 7: LPC11U3x/2x/1x I/O configuration
7.4.1.7 PIO0_6 register
7:3 - - Reserved. 10000
9:8 I2CMODE Selects I2C mode (see Section 7.3.8
).
Select Standard mode (I2CMODE = 00, default) or Standard
I/O functionality (I2CMODE = 01) if the pin function is GPIO
(FUNC = 000).
00
0x0 Standard mode/ Fast-mode I2C.
0x1 Standard I/O functionality
0x2 Fast-mode Plus I2C
0x3 Reserved.
31:10 - - Reserved. -
Table 81. PIO0_5 register (PIO0_5, address 0x4004 4014) bit description
…continued
Bit Symbol Value Description Reset
value
Table 82. PIO0_6 register (PIO0_6, address 0x4004 4018) bit description
Bit Symbol Value Description Reset
value
2:0 FUNC Selects pin function. Values 0x4 to 0x7 are reserved. 000
0x0 PIO0_6.
0x1 USB_CONNECT
.
0x2 SCK0.
0x3 SCK0.IOH_4
4:3 MODE Selects function mode (on-chip pull-up/pull-down resistor
control).
10
0x0 Inactive (no pull-down/pull-up resistor enabled).
0x1 Pull-down resistor enabled.
0x2 Pull-up resistor enabled.
0x3 Repeater mode.
5 HYS Hysteresis. 0
0 Disable.
1 Enable.
6 INV Invert input 0
0 Input not inverted (HIGH on pin reads as 1, LOW on pin reads
as 0).
1 Input inverted (HIGH on pin reads as 0, LOW on pin reads as
1).
9:7 - - Reserved. 001
10 OD Open-drain mode. 0
0 Disable.
1 Open-drain mode enabled.
Remark: This is not a true open-drain mode.
31:11 - - Reserved. 0
