Chapter 7: LPC11U3x/2x/1x I/O configuration
7.4.1.26 PIO1_1 register
10 OD Open-drain mode. 0
0 Disable.
1 Open-drain mode enabled. This is not a true open-drain
mode. Input cannot be pulled up above VDD.
31:11 RESERVED Reserved. 0
Table 100. PIO1_0 register (PIO1_0, address 0x4004 4060) bit description
…continued
Bit Symbol Value Description Reset
value
Table 101. PIO1_1 register (PIO1_1, address 0x4004 4064) bit description
Bit Symbol Value Description Reset
value
2:0 FUNC Selects pin function. Values 0x3 to 0x7 are reserved. 0
0x0 PIO1_1.
0x1 CT32B1_MAT1.
0x2 IOH_11
4:3 MODE Selects function mode (on-chip pull-up/pull-down resistor
control).
0x2
0x0 Inactive (no pull-down/pull-up resistor enabled).
0x1 Pull-down resistor enabled.
0x2 Pull-up resistor enabled.
0x3 Repeater mode.
5 HYS Hysteresis. 0
0 Disable.
1 Enable.
6 INV Invert input 0
0 Input not inverted (HIGH on pin reads as 1, LOW on pin reads
as 0).
1 Input inverted (HIGH on pin reads as 0, LOW on pin reads as
1).
9:7 RESERVED Reserved. 0x1
10 OD Open-drain mode. 0
0 Disable.
1 Open-drain mode enabled. This is not a true open-drain
mode. Input cannot be pulled up above VDD.
31:11 RESERVED Reserved. 0
