UM10462 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2016. All rights reserved.
User manual Rev. 5.5 — 21 December 2016 393 of 523
NXP Semiconductors
UM10462
Chapter 20: LPC11U3x/2x/1x Flash programming firmware
20.8 ISP/IAP communication protocol
All ISP commands should be sent as single ASCII strings. Strings should be terminated
with Carriage Return (CR) and/or Line Feed (LF) control characters. Extra <CR> and
<LF> characters are ignored. All ISP responses are sent as <CR><LF> terminated ASCII
strings. Data is sent and received in UU-encoded format.
20.8.1 ISP command format
"Command Parameter_0 Parameter_1 ... Parameter_n<CR><LF>" "Data" (Data only for
Write commands).
20.8.2 ISP response format
"Return_Code<CR><LF>Response_0<CR><LF>Response_1<CR><LF> ...
Response_n<CR><LF>" "Data" (Data only for Read commands).
20.8.3 ISP data format
The data stream is in UU-encoded format. The UU-encode algorithm converts 3 bytes of
binary data in to 4 bytes of printable ASCII character set. It is more efficient than Hex
format which converts 1 byte of binary data in to 2 bytes of ASCII hex. The sender should
send the check-sum after transmitting 20 UU-encoded lines. The length of any
UU-encoded line should not exceed 61 characters (bytes) i.e. it can hold 45 data bytes.
The receiver should compare it with the check-sum of the received bytes. If the
check-sum matches then the receiver should respond with "OK<CR><LF>" to continue
further transmission. If the check-sum does not match the receiver should respond with
"RESEND<CR><LF>". In response the sender should retransmit the bytes.
20.8.4 ISP flow control
A software XON/XOFF flow control scheme is used to prevent data loss due to buffer
overrun. When the data arrives rapidly, the ASCII control character DC3 (stop) is sent to
stop the flow of data. Data flow is resumed by sending the ASCII control character DC1
(start). The host should also support the same flow control scheme.
20.8.5 ISP command abort
Commands can be aborted by sending the ASCII control character "ESC". This feature is
not documented as a command under "ISP Commands" section. Once the escape code is
received the ISP command handler waits for a new command.
20.8.6 Interrupts during ISP
The boot block interrupt vectors located in the boot block of the flash are active after any
reset.
