Chapter8 Optional Accessories (Sold Separately)
F3SG-SR
User’s Manual
Appendix
Intelligent Tap
Intelligent Tap Bracket
Root-Straight Cable for IO-Link
Bluetooth
®
Communication Unit
Y-Joint Plug/Socket Connector
Reset Switch Connector
Appearance Model Application Remarks
F39-SGIT-IL3 Used to configure the
F3SG-SR and
connect external
devices via IO-Link.
Material: PBT resin (Body parts)
Appearance Model Application Remarks
F39-LITF1 Bracket to mount the
Intelligent Tap on a
DIN track.
Material: PBT resin (Body parts)
Appearance Model Application Remarks
XS5F-D521-DJ0-IL 2 m M12 connector (5-pin), 5 wires.
Used to connect an Intelligent Tap to an
IO-Link Master unit of Push-in Terminal
Block type.
Appearance Model Application Remarks
F39-SGBT Mounted to the
Intelligent Tap to
connect with the SD
Manager 3 via
Bluetooth.
Material: PBT resin (Body parts)
Appearance Model Application Remarks
F39-GCNY2 0.5 m M12 connectors
Used for reduced wiring.
Appearance Model Application Remarks
F39-GCNY3 3 m M12 connectors.
Used for reduced wiring when connecting
to a reset switch.
To Next Page
