Chapter8 Optional Accessories (Sold Separately)
F3SG-SR
User’s Manual
Appendix
Control Unit
Control Unit
Control Unit
Appearance Model Output Remarks
G9SA-301
G9SA-321-T075
G9SA-321-T15
G9SA-321-T30
Safety output (relay):
NO contact x 3
Auxiliary output (relay):
NC contact x 1
• An F39-JGC Root-Straight
Cable or the combination of an
F39-JGR3K Root-Plug Cable for
Extended and an F39-JGA
Single-Ended Cable is required.
• An F3SG-SR in PNP system can
be connected.
G9SA-501 Safety output (relay):
NO contact x 5
Auxiliary output (relay):
NC contact x 1
Appearance Model Output Remarks
G9SA-301-P Safety output (relay): NO
contact x 3
Auxiliary output (relay): NC
contact x 1
• An F39-JGC Root-Straight
Cable or the combination of an
F39-JGR3K Root-Plug Cable for
Extended and an F39-JGA
Single-Ended Cable is required.
• An F3SG-SR in NPN system can
be connected.
Appearance Model Output Remarks
G9SB-301-B Safety output (relay): NO
contact x 3
Auxiliary output (relay): NC
contact x 1
Auto reset
• An F39-JGC Root-Straight
Cable or the combination of an
F39-JGR3K Root-Plug Cable for
Extended and an F39-JGA
Single-Ended Cable is required.
• An F3SG-SR in PNP system can
be connected.
G9SB-301-D Safety output (relay): NO
contact x 3
Auxiliary output (relay): NC
contact x 1
Manual reset
G9SB-200-B Safety output (relay): NO
contact x 2
Auto reset
G9SB-200-D Safety output (relay): NO
contact x 2
Manual reset
