Panasonic FP Series User Manual

Appendix Programming Information
1281
Using the pulse I/O cassette:
The input modes two-phase, incremental/decremental, or
incremental/decremental control require a second channel. If channel 8, or
channel A have been set to one of these modes, the settings for channel 9, and
channel B, respectively, will be invalid.
If reset input settings overlap for channel 8 and channel 9, the channel 9 setting
takes precedence. If reset input settings overlap for channel A and channel B,
the channel B setting takes precedence.
System registers 400 applies when the pulse I/O cassette is installed in cassette
mounting part 0. System register 401 applies when the pulse I/O cassette is
installed in cassette mounting part 1.
Input numbers X102 and X202 can be used as home input of pulse output
channels 0 and 1. When using the home return function, always set the home
input. In this case, X102 and X202 cannot be used as reset inputs for channels 8
to B.
System registers 404/406 apply when the pulse I/O cassette is used.
Time Constants
No. Name Default Values
430 Time constant of input X0
430 Time constant of input X1
430 Time constant of input X2
430 Time constant of input X3
431 Time constant of input X4
431 Time constant of input X5
431 Time constant of input X6
431 Time constant of input X7
432 Time constant of input X8
432 Time constant of input X9
432 Time constant of input XA
432 Time constant of input XB
433 Time constant of input XC
433 Time constant of input XD
433 Time constant of input XE
433 Time constant of input XF
434 Time constant of input X10
434 Time constant of input X11
434 Time constant of input X12
434 Time constant of input X13
435 Time constant of input X14
435 Time constant of input X15
435 Time constant of input X16
435 Time constant of input X17
436 Time constant of input X18
436 Time constant of input X19
436 Time constant of input X1A
436 Time constant of input X1B
437 Time constant of input X1C
Unused 1.0ms
2.0ms
4.0ms
8.0ms
16.0ms
32.0ms
64.0ms
128.0ms
256.0ms
