Panasonic FP Series User Manual

Appendix Programming Information
1285
No. Name Default Values
43 PLC link 0 - Link relays - Send area - Number of words to send 0 0–64 words
41 PLC link 0 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
44 PLC link 0 - Link registers - Send area - Start sending from this
word address
0 0–127
45 PLC link 0 - Link registers - Send area - Number of words to send 0 0–127 words
57 PLC link 1 - Highest station number in network 16 1–16
50 PLC link 1 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
52 PLC link 1 - Link relays - Send area - Start sending from this word
address
64 64–127
53 PLC link 1 - Link relays - Send area - Number of words to send 0 0–64 words
51 PLC link 1 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
54 PLC link 1 - Link registers - Send area - Start sending from this
word address
128 128–255
55 PLC link 1 - Link registers - Send area - Number of words to send 0 0–127 words
High-Speed Counter, Pulse Catch Input, Interrupt Input
No.
Name Default Values
400 High-speed counter:
Channel 0
Unused  Two-phase input (X0, X1)
 Two-phase input (X0, X1), Reset input (X2)
 Incremental input (X0)
 Incremental input (X0), Reset input (X2)
 Decremental input (X0)
 Decremental input (X0), Reset input (X2)
 Incremental input (X0), Decremental input (X1)
 Incremental input (X0), Decremental input (X1), Reset input (X2)
 Counter input (X0), Incremental/decremental control input (X1)
 Counter input (X0), Incremental/decremental control input (X1),
Reset input (X2)
400 High-speed counter:
Channel 1
Unused  Incremental input (X1)
 Incremental input (X1), Reset input (X2)
 Decremental input (X1)
 Decremental input (X1), Reset input (X2)
401 High-speed counter:
Channel 2
Unused  Two-phase input (X3, X4)
 Two-phase input (X3, X4), Reset input (X5)
 Incremental input (X3)
 Incremental input (X3), Reset input (X5)
 Decremental input (X3)
 Decremental input (X3), Reset input
 Incremental input (X3), Decremental input (X4)
 Incremental input (X3), Decremental input (X4), Reset input
 Counter input (X0), Incremental/decremental control input (X5)
 Counter input (X3), Incremental/decremental control input (X4),
Reset input X5)
401 High-speed counter:
Channel 3
Unused  Incremental input (X4)
 Incremental input (X4), Reset input (X5)
 Decremental input (X4)
 Decremental input (X4), Reset input (X5)
