Panasonic FP Series User Manual

Appendix Programming Information
1302
No. Name Default Values
30 Watchdog timer time-out FP2: 627.5ms
FP2SH/FP10SH: 100.0ms
FP2: Fixed
FP2SH/FP10SH: 0.4–640.0ms
31 Multi-frame
communication time
FP2/FP2SH: 10000ms
FP10SH: 6500.0ms
FP2: 10.0–81900.0ms
FP2SH/FP10SH: 10.0–81917.5ms
32 Timeout value for the
communication functions
based on F145, F146,
F152, F153
10000.0ms FP2: 10.0–81900.0ms
FP2SH/FP10SH: 10.0–81917.5ms
33 Effective time setting for
monitoring
FP2: 10000.0
s
FP2SH/FP10SH: 163837.5
s
FP2: 2000–52428.0
s
FP2SH/FP10SH: 2500.0–163837.5
s
34 Constant scan time 0.0ms FP2: 0.0–620.0ms
FP2SH/FP10SH: 0.0–640.0ms
0.0: Normal scan (non-constant)
1)
FP2SH/FP10SH only
MEWNET-F
No. Name Default Values
25 PLC start mode when MEWNET-F slave stations
connection timeout occurs
Stop Stop/Continue
35 Wait mode for checking connection Wait Wait/Don't wait
35 MEWNET-F slave stations connection timeout 0s 0–255s
36 Remote I/O update method Synchronous Synchronous/Asynchronous
PLC Link
No. Name Default Values
46 PLC Link 0 and 1 allocation setting Normal Normal/Reverse
47
1)
PLC link 0 - Highest station number in network 16 1–16
40 PLC link 0 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
42 PLC link 0 - Link relays - Send area - Start sending from this word
address
0 0–63
43 PLC link 0 - Link relays - Send area - Number of words to send 0 0–64 words
41 PLC link 0 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
44 PLC link 0 - Link registers - Send area - Start sending from this
word address
0 0–127
45 PLC link 0 - Link registers - Send area - Number of words to send 0 0–127 words
57
1)
PLC link 1 - Highest station number in network 16 1–16
50 PLC link 1 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
52 PLC link 1 - Link relays - Send area - Start sending from this word
address
64 64–127
53 PLC link 1 - Link relays - Send area - Number of words to send 0 0–64 words
51 PLC link 1 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
54 PLC link 1 - Link registers - Send area - Start sending from this
word address
128 128–255
