Panasonic FP Series User Manual

Appendix Programming Information
1303
No. Name Default Values
55 PLC link 1 - Link registers - Send area - Number of words to send 0 0–127 words
1)
Not for FP10SH
PROFIBUS/MEWNET-H
No. Name Default Values
49 PROFIBUS, MEWNET-H link access method/scan 0
0–65535 (
256 bytes)
TOOL Port
FP2/FP2SH
No
.
Name Default Values
410 TOOL port - station number 1 1–32
411 TOOL port - modem connection Disable Disable/Enable
411 TOOL port - sending data
length
8 bits 7 bits/8 bits
414 TOOL port - baud rate 115200 baud 115200/57600/38400/19200/9600/4800/2400/1200 baud
FP10SH
No
.
Name Default Values
414 TOOL port - baud rate 115200 baud 115200/57600/38400/19200/9600/4800/2400/1200 baud
COM Port
FP2/FP2SH
No. Name Default Values
412 COM port 1 - communication mode MEWTOCOL-COM
Slave
MEWTOCOL-COM Slave/Program
controlled
415 COM port 1 -station number 1 1–32
414 COM port 1 - baud rate FP2: 19200 baud
FP2SH: 9600 baud
115200/57600/38400/19200/9600/4800
/2400/1200 baud
413 COM port 1 - sending data length 8 bits 7 bits/8 bits
413 COM port 1 -sending parity check With-Odd None/With-Odd/With-Even
413 COM port 1 - sending stop bit 1 bit 1 bit/2 bits
413 COM port 1 - sending start code No-STX No-STX/STX
413 COM port 1 - sending end
code/reception done condition
CR CR/CR+LF/ETX/None
417 COM port 1- -receive buffer starting
address
0 FP2: 0–5997
FP2SH, 60k: 0–10237
FP2SH, 120k: 0–10235
418 COM port 1 - receive buffer capacity 0 FP2: 0–2048
FP2SH: 0–1024

Panasonic FP Series Specifications

General

Mounting	DIN rail
Type	PLC
Communication Interface	RS-232, RS-485, Ethernet (depending on model)
Input Voltage	100-240V AC or 24V DC (depending on model)
Output Type	Relay, Transistor
I/O Points	Varies by model
Operating Temperature	0°C to 55°C
Dimensions	Varies by model
Weight	Varies by model
