Simrad EK15 User Manual

Displayviews
Ifyouclickinanechogram,theechogramisselectedtobe“active”.The“active”
echogramisidentiedwithathickborder.Ifyouchangeparametersrelatedtothe
echograms,thesearebydefaultonlyappliedtothe“active”echogram.
Tip
Youcanmodifythesizeoftheechogramsbymovingtheboundarylinesbetween
theechograms.Clickonaboundaryline,holdthebuttondepressed,andmovethe
linehorizontallyorvertically.
CMenusystem
Themenusystemisbydefaultlocatedontherighthandsideofthe
presentation.Toopenanyofthesubmenus,clickthebuttonsunderthe
Mainmenu.Tohideorretrievetheentiremenusystem,clicktheMenu
buttonontheTitleBar.
DStatusBar
TheStatusBarislocatedatthebottomoftheEK15presentation.
EReplayBar
DuringreplayadedicatedReplayBarisprovidedbelowtheTitleBar.TheReplay
Barallowsyoutoretrievesavedles,andtocontroltheplayback.
FSubmenus
Thesubmenusareopenedandclosedbyclicking
thebuttonsatthebottomoftheMainmenu.
GInformationpanes
YoucanchoosefromseveralInformationpanestoprovideyouwithadditionaldata.
ThesepanesareselectedfromthebuttonsontheTitleBar.Thepanescanbemoved
aroundontheechogrampresentation,andyoucanchangetheirsizes.Thepanesare
transparent,soechograminformationdisplayedbehindthemarenotlost.
Relatedtopics
•TitleBaronpage106
•Echogramsonpage116
•Replaybaronpage114
•Menusystemonpage115
•Informationpanesonpage124
•StatusBaronpage128
351718/C
105
